Danfoss FC-302P4K0T5E20H2XGXXXXSXXXXA0BXCXXXXDX Low Voltage Inverter - 131B0494

Danfoss FC-302P4K0T5E20H2XGXXXXSXXXXA0BXCXXXXDX Low Voltage Inverter - 131B0494

Product Details

Danfoss FC-302P4K0T5E20H2XGXXXXSXXXXA0BXCXXXXDX 131B0494 low-voltage inverter. Danfoss VLT® AutomationDrive FC 301 low-voltage drive. The Danfoss/Danfoss VLT® AutomationDrive is designed for variable speed control of all asynchronous and permanent magnet motors. It can be divided into FC 301 Standard and FC 302 Advanced High Dynamic.

With its thermal design and back-duct cooling, Danfoss VLT® AutomationDrive is one of the most innovative drives on the market. New smart maintenance features and a range of DrivePro® services proactively improve productivity, performance and uptime. The drives are rugged and durable, allowing them to operate efficiently and reliably, even in applications and challenging environments.

Danfoss FC-302P4K0T5E20H2XGXXXXSXXXXA0BXCXXXXDX Low-Voltage Inverter - 131B0494

Danfoss VLT® AutomationDrive FC 301 Low Voltage Inverter Features and Benefits

● Extremely wide operating temperature range from -25 °C to +50 °C without the need for capacity reduction, ensuring reliable operation even when the frequency converter is in ambient conditions.

● Flexible, modular design concept provides an extremely versatile motor control solution.

●The back-air duct cooling concept reduces costs, energy consumption and the size of the cooling system.

●New “vibration-resistant” design to minimize the effects of possible undesirable vibrations

● Reduced need for PLC capacity thanks to intelligent logic control

Low lifetime costs due to the inverter's high resistance to wear and tear

●Extended service life of electronic components thanks to back-air duct cooling in chassis D, E, and F

●Easy commissioning and upgrading thanks to plug-in technology

●High-precision positioning and synchronization thanks to integrated motion controllers that can be used across the entire product range

●Safe and energy-efficient operation of the frequency converter thanks to intelligent thermal management, safe stopping and safe torque shutdown

●VLT® Motion Control Tool MCT 10 for customized commissioning

Supply voltage and power range

3 x 200-240 V.. . 0.25-37 kW

3 x 380-500 V... .0.37 kW - 1.1 MW

3 x 525-600 V.... .0.75-75 kW

3 x 525-690 V.... .1.1 kW - 1.4 MW

Low harmonic frequency converters

3 x 380-480 V... .132-450 kW

12 Pulse inverters

3 x 380-500 V... . 250 kW - 1 MW

3 x 525-690 V.... .250 kW - 1.4 MW
